Ingebouwde processor:Ja
Geheugen buffer:4 MB
Type switch:Managed
Switch laag:L3
Switch capaciteit:480 Gbit/s
Web-based management:Ja
Behuizing:1U
Kleur:Zwart
Rack montage:Ja
Stapelbaar:Ja
Aantal stapelbare units:4
Aantal fans:3 ventilator(en)
Warmte afvoer:557, 94 BTU/h
Ethernetsnelheid:Gigabit Ethernet (10/100/1000)
Netwerkstandaard:IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3x
Bekabelingstechnologie:1000BASE-T, 100BASE-T, 10BASE-T, 10GBASE-T
10G ondersteuning:Ja
MAC adres tabel:48000 entries
Multicast ondersteuning:Ja
Doorvoersnelheid:12 Mpps, 357
Head-of-line (HOL) blocking:Ja
Datastroombeheer:Ja
Full duplex:Ja
Port mirroring:Ja
MIB ondersteuning:RFC1065, RFC1066, RFC1155, RFC1156, RFC1157, RFC1191, RFC1212, RFC1213, RFC1215, RFC1321, RFC1338, RFC1398, RFC1442, RFC1493, RFC1519, RFC1643, RFC1650, RFC1724, RFC1757, RFC1759, RFC1850, RFC1886, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC1981, RFC2003, RFC2021, RFC2284, RFC2358, RFC2460, RFC2461, RFC2462, RFC2463, RFC2464, RFC2465, RFC2466, RFC2474, RFC2571, RFC2572, RFC2573, RFC2574, RFC2575, RFC2576, RFC2578, RFC2618, RFC2620, RFC2665, RFC2668, RFC2674, RFC271, RFC2716, RFC2737, RFC2767, RFC2787, RFC2819, RFC2863, RFC2865, RFC2893, RFC2925, RFC2932, RFC2934, RFC3168, RFC3246, RFC3247, RFC3260, RFC3298, RFC3418, RFC3484, RFC3513, RFC3580, RFC3635, RFC3636, RFC3748, RFC4022, RFC4113, RFC4188, RFC4213, RFC4291, RFC4292, RFC4293, RFC4363, RFC4443, RFC4861, RFC4862, RFC4884, RFC5132, RFC5415, RFC768, RFC791, RFC792, RFC793, RFC826
ARP controle:Ja
Link aggregatie:Ja
Ethernet poorten (RJ-45):20
SFP slots (Combi):4
SFP slots:4
Optische glasvezel:SFP+
Console poort:RJ-45
USB 2.0:1
Power over Ethernet (PoE):Nee
VLAN ondersteuning:Ja
VLAN mogelijkheden:MAC address-based VLAN, Port-based VLAN, Private VLAN, Voice VLAN
Aantal VLAN's:4094
Beveiligingsalgoritmen:802.1x RADIUS
Authenticatie:Gast-VLAN, MAC-gebaseerde authenticatie, Poortgebaseerde authenticatie
ACL:Ja
SSH/SSL ondersteuning:Ja
IGMP snooping:Ja
Loop beveiliging:Ja
BPDU filtering/bescherming:Ja
DHCP functies:DHCP client, DHCP server
Veiligheidsstandaarden:BSMI, CB, CCC, CE, cUL
Stroomverbruik (max):159, 8 W
Ingangsspanning:100 – 240 V
Ingangsfrequentie:50 – 60 Hz
Invoerstroom:2 A
Gewicht:6, 65 kg
Hoogte:44 mm
Breedte:441 mm
Diepte:380 mm
